l 抗分光光度计线，厚实，防火等级
l 绿色环保规格：RoHS
l 标准规范背景色：黄、白（各种背景色可为您加工定制）
耐腐蚀性 | RSFR | AMS | DIN | HNF |
弯曲刚度 | ≥10.3 MPa | ≥10.3 MPa | ≥10.3 MPa | ≥10.3 MPa |
断开受力率 | ≥200% | ≥200% | ≥200% | ≥200% |
热脱落后收缩承载力 | ≥6.9 MPa | ≥6.9 MPa | ≥6.9 MPa | ≥6.9 MPa |
热退化后崩裂拉伸应变率 | ≥100% | ≥100% | ≥100% | ≥100% |
耐油性 | VW-1 | VW-1 | S3级 | I2，F2 |
热冲击试验 | 无裂缝、无滴落 | 无划痕、无滴落 | 无龟裂、无滴落 | 无波浪纹、无滴落 |
冷弯柔性板 | 无划痕 | 无龟裂 | 无内裂 | 无磨痕 |
吸附率 | ＜0.5% | ＜0.5% | ＜1.0% | ＜1.0% |
损坏屈服强度 | ≥19.7 MV/m | ≥19.7 MV/m | ≥19.7 MV/m | ≥19.7 MV/m |
量电阻功率率 | ≥1014 Ω·cm | ≥1014 Ω·cm | ≥1014 Ω·cm | ≥1014 Ω·cm |
注音：测试技巧与RSFR/AMS/DIN/HNF广告管应对的做法同一。
数字序号 | 定购项目编码 | 包装袋总数量 (片/卷) | 标示 宽度 (mm) | 标示 粗度 (mm) | 打印出空间 (mm) | 选用的范围 (mm) | |
高宽比 | 段长度 | ||||||
1 | RSFR-4H-10.4-45-2K-W-B-P0-* | 2000 | 10.4 | 45 | 6.4 | 25 | 5.08~12.7 |
2 | RSFR-4H-10.4-53-2K-W-B-P0-* | 2000 | 10.4 | 53 | 6.4 | 33 | 5.08~12.7 |
3 | RSFR-4H-10.4-64-2K-W-B-P0-* | 2000 | 10.4 | 64 | 6.4 | 44 | 5.08~12.7 |
4 | RSFR-6H-10.4-76-2K-W-B-P0-* | 2000 | 10.4 | 76 | 6.4 | 56 | 5.08~12.7 |
5 | RSFR-6H-10.4-90-2K-W-B-P0-* | 2000 | 10.4 | 90 | 6.4 | 70 | 5.08~12.7 |
6 | RSFR-4H-12.0-102-2K-W-B-P0-* | 2000 | 12.0 | 102 | 8.0 | 82 | 12.7~19.1 |
7 | RSFR-4H-15.0-45-1.5K-W-B-P0-* | 1500 | 15.0 | 45 | 11.0 | 25 | 12.7~19.1 |
8 | RSFR-4H-15.0-53-1.5K-W-B-P0-* | 1500 | 15.0 | 53 | 11.0 | 33 | 12.7~19.1 |
9 | RSFR-4H-15.0-64-1.5K-W-B-P0-* | 1500 | 15.0 | 64 | 11.0 | 44 | 12.7~19.1 |
10 | RSFR-6H-15.0-76-1.5K-W-B-P0-* | 1500 | 15.0 | 76 | 11.0 | 56 | 12.7~19.1 |
11 | RSFR-6H-15.0-90-1.5K-W-B-P0-* | 1500 | 15.0 | 90 | 11.0 | 70 | 12.7~19.1 |
12 | RSFR-4H-20.3-45-1K-W-B-P0-* | 1000 | 20.3 | 45 | 16.3 | 25 | 19.1~25.4 |
13 | RSFR-4H-20.3-53-1K-W-B-P0-* | 1000 | 20.3 | 53 | 16.3 | 33 | 19.1~25.4 |
14 | RSFR-4H-20.3-64-1K-W-B-P0-* | 1000 | 20.3 | 64 | 16.3 | 44 | 19.1~25.4 |
15 | RSFR-6H-20.3-76-1K-W-B-P0-* | 1000 | 20.3 | 76 | 16.3 | 56 | 19.1~25.4 |
16 | RSFR-6H-20.3-90-1K-W-B-*-P0-* | 1000 | 20.3 | 90 | 16.3 | 70 | 19.1~25.4 |
17 | RSFR-4H-25.4-45-1K-W-B-*-P0-* | 1000 | 25.4 | 45 | 21.4 | 25 | 25.4 and up |
18 | RSFR-4H-25.4-53-1K-W-B-*-P0-* | 1000 | 25.4 | 53 | 21.4 | 33 | 25.4 and up |
19 | RSFR-4H-25.4-64-1K-W-B-*-P0-* | 1000 | 25.4 | 64 | 21.4 | 44 | 25.4 and up |
20 | RSFR-6H-25.4-76-1K-W-B-*-P0-* | 1000 | 25.4 | 76 | 21.4 | 56 | 25.4 and up |
21 | RSFR-6H-25.4-90-1K-W-B-*-P0-* | 1000 | 25.4 | 90 | 21.4 | 70 | 25.4 and up |
