产品参数:
□ 额定功率输出功率 Rated Voltage:750 V DC/1000 V DC
□ 固定交流电 Rated Current:80A/125A/200A/250A
□ 耐压功率电阻 Insulation Resistance:≥500MΩ
□ 耐电压降 Withstand Voltage:3500V AC
□ 机械性使用期Mechanical Lifetime:≥10000 cycles (no-load)
□ 插拔力 Insertion and Separation Forces:F<140N
□ 预防级别为Protection Degree:IP55
□ 周围环境平均温度 Operating Temperature:-30℃~50℃
□ 相对湿度 Operating Moisture:5%~95%(40℃)
□ 抗静电级别为 Flame Retardant Grade:Ul94 V-0
□ 锁止培训机构类Type of Locking Mechanism:电磁波锁electromagnetic lock structure
